SCB2 Cage Rod Cross Coupler

Product Description

• 4-40 thread on one end, M3 thread on the other
• Accepts Ø6 mm PCMS series rods internally
• Connects Ø6 mm cage rods at 90°
• Vertically links multiple 30 mm and 60 mm cage structures
• Precision-machined stainless steel, high flexibility, excellent alignment compatibility

The cage rod cross coupler connects multiple 30 mm and 60 mm cage structures vertically at 90°. Its flexible design simplifies alignment and facilitates setup and integration of cage systems.



Specification	SCB2
Dimensions	Ø8.9×12.7 mm
Through Hole	Ø6 mm
Thread Type	4-40, M3
Weight	4.1 g
Material	304 Stainless Steel

Technical Description

(1) The cage rod cross coupler connects multiple 30 mm and 60 mm cage structures vertically at 90°. It offers high flexibility, streamlines alignment, and simplifies the assembly and integration of cage systems.、

(2) It has an internal Ø6 mm locating hole. One end has a 4-40 threaded hole and the other an M3 threaded hole. PCMS series cage rods can be inserted into the hole and secured with a 1.5 mm hex wrench, or screwed directly into the threaded holes.

(3) The M3 thread end can attach directly to the OPSM2 universal base plate to vertically mount a 30 mm cage assembly. Multi-threaded hole arrays allow component mounting in all directions, increasing the flexibility of optical setups.

Assembly

Application Examples

Engineering Drawings

SCB2 Engineering Drawing
